Drilled water boreholes in Uganda

We have worked on a number of drilling projects including;

We have worked in different regions of the country including the central, Eastern, Western, and Northern gaining more experience in handling different soil formations, and different rock types.

Listed below is some of our selected drilled water boreholes

Borehole drilling in Bugiri

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pump testing	Pumping system Installation(Hybrid)
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	On going
Borehole details	Recommended drilling depth= up to 75 meters	75 meters, open hole casing	Three step tests 1.5m3/hr, 2.5m3/hr and 4.5m3/hr each one hour Constant pumping for 24hrs at 4m3/hr Recovery 96.1% in 1 hr

Borehole purpose

Some field photos

Short video

Borehole drilling in Kapeeka

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pump testing	Pumping system Installation(Hybrid)
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	On going
Borehole details	Recommended drilling depth= up to 70 meters	45 meters, closed hole casing	Three step tests 7.5m3/hr, and 15m3/hr each one hour Constant pumping for 24hrs at 10m3/hr Recovery 94.17% in 1 hr

Borehole purpose

• Community water supply (School, hospital and general community)

Some field photos

Short video

Borehole drilling in Nakapiripit

Borehole details

Activity		Drilling and siting	Pumptesting	Pump Installation
Contractor	other	Weis Engineering	Weis Engineering
Borehole details	Recommended drilling depth= up to 70 meters	100 meters, open hole casing	Three step tests 0.3m3/hr, 0.6m3/hr and 1.0m3/hr each one hour Constant pumping for 12hrs at 0.5m3/hr Recovery 96.1% in 1 hr

Borehole purpose

• Provide water for community and basic industrial use

Some field photos

Short videos

Borehole drilling in Lwengo

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 2m3/hr, Expected drilling depth= up to 100 meters	100 meters, full casing	Two Step tests 1.5m3/hr, 2.5m3/hr, and 4 m3/hr each one hour Constant pumping for 72hrs at 2.0m3/hr Recovery 99% in 1 hr	Hybrid (Uses both AC and DC, Multi-led digital pump inverter with remotely controlled function

Borehole purpose

• Provide water for community (Institute)

Some field photos

Short video

Borehole drilling in Jinja

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 1m3/hr, Expected drilling depth= up to 70 meters	60 meters, open hole casing	Two Step tests 1.1m3/hr for 1 hr, and 2.1m3/hr for 40 minutes) Constant pumping for 24hrs at 1.3m3/hr Recovery 96.1% in 1 hr

Borehole purpose

• Provide water for domestic and basic irrigation

Some field photos

Borehole flushing demo videos

Borehole drilling in Wakiso

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 3m3/hr, Expected drilling depth= up to 85 meters	70 meters, Full bottom casing to 65 meters	Four step tests 1.5, 3m3/hr for 1hr and 4.3m3/hr for 3 mins. Constant pumping for 24hrs at 2.5m3/hr Recovery 98% in 55mins.

Borehole purpose

• Provide water for school the community

Some field photos

Borehole drilling in Yumbe

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 2m3/hr, Expected drilling depth= up to 80 meters	70 meters, open hole casing	Step tests = 2 each 1.0hrs (1.53, & 2.04m3/hr) Constant pumping for 24hrs at 1.2m3/hr Recovery 98% in 1 hr

Borehole purpose

• Provide water for Moslem community – prayers, school and the community

Some field photos

---

Borehole drilling in Kasanda

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 3m3/hr, Expected drilling depth= up to 120 meters	70 meters, Full bottom casing	Step tests = 5 each 1.5hrs (1.5, 2.5.3.5, 4.5 &5.5m3/hr) Constant pumping for 24hrs at 4.5m3/hr Recovery 91% in 1 hr

Borehole purpose

• Basic industrial use
• Basic irrigation water
• Domestic use

Some field photos

Borehole drilling in Mubende

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 3m3/hr, Expected drilling depth= up to 120 meters	77 meters, Open hole casing	Step tests = 3 each 1.5hrs (2.5, 4.5, &6.5m3/hr) Constant pumping for 72hrs at 3.3m3/hr Recovery 99% in 1 hr	Grundfos SQfelx

Borehole purpose

• Irrigation water for 2.2 acres

Some field photos

Borehole drilling in Kapeeka

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	on hold	on hold
Borehole details	Expected yield = 2m3/hr, Expected drilling depth= up to 85 meters	70 meters, full bottom casing	on hold	on hold

Borehole purpose

• 2 acres irrigation
• Livestock
• Domestic use

Some field photos

Borehole drilling in Pallisa

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	pending
Borehole details	Expected yield = 3.5m3/hr, Expected drilling depth= up to 75 meters	75 meters,open hole	7.2m3/hr	pending

Borehole purpose

• Domestic use
• Livestock
• Irrigation

Some field photos

Demo video – Borehole flushing

Borehole drilling in Yumbe II

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	pending
Borehole details	Expected yield = 1.5m3/hr, Expected drilling depth= up to 65 meters	65 meters,open hole	1.2m3/hr	pending

Borehole purpose

• Community water use

Some field photos

Borehole drilling in Serere

Borehole purpose

• Domestic use and irrigation

Borehole details

Activity	Hydrogeological survey	Drilling and siting	Pumptesting	Pump Installation
Contractor	Weis Engineering	Weis Engineering	Weis Engineering	Weis Engineering
Borehole details	Expected yield = 4m3/hr, Expected drilling depth= up to 70 meters	50 meters, Full casing	6.8m3/hr	Ongoing(Solar powered)

Some field photos

Sample videos

Borehole drilling supervision in Ibanda 1

Borehole drilling supervision in Ibanda 2

Borehole drilling supervision in Ibanda 3

Borehole drilling supervision in Ibanda 4
